Excellent quality of service (QoS)

Protection against interference

Digital Radio Technology

For demanding work environments

Advanced Scalability

New Wireless Intercom Beltpack

Xplorer MAX is a wireless Intercom beltpack based on ground-breaking, high-performance digital radio technology. It comes with full intercom user-panel features and functions, with four direct access keys organized in up to 4 pages, two additional programmable keys, and a multi-function display. It can operate with any AEQ intercom matrix such as Conexia, Crossnet or TH5000. It is also integrating with Xpeak, AEQ’s matrix-less Intercom system, or as a terminal for the Party-Line Easynet system.

Taking Wireless Intercom to Next Level

Technical Specifications of the Radio System

Operation with matrices

Xplorer MAX can be operate as a client and part of AEQ’s intercom matrices Crossnet, Conexia, and TH5000. In this mode, each key can activate commands such as Talk, Listen, Talk&Listen, Remote One Way, Remote Both Ways, Remote Volume, and Dial Call. In this ecosystem can be added wired intercom user panels such us the 8000 and 9000 series and the Olympia 3 commentator units. Additionally, using Xvirtual application, it can connect with: intercom user panels on iOS devices (iPad and iPhone) and Windows PCs.

Matrix-less Operation

Xplorer MAX can also be used in matrix-less Xpeak systems. In
this mode, each key can activate the same commands as when
in matrix mode.
This type of systems are normally built with:
• Wired user panels Xpeak_R and Xpeak_D.
• Wired beltpacks Xpeak_BP.
• Virtual panel for PC Xpeak Virtual.
• Input and output interfaces Xpeak_IF.

Party-Line Mode

Xplorer MAX also operates in Party-Line mode without the need for a matrix, functioning as a terminal in the Easynet system, with 4 independent channels and up to 28 devices.

Xplorer MAX Technical features

Features

Connectivity: Multi-carrier digital radio system in the 5GHz band.
Can operate as a client of AEQ Crossnet, Conexia, and TH5000 intercom matrices.
Can work without a matrix in Xpeak and Party-Line modes.
Matrix-free operation features:
– 4 channels.
– Each terminal can receive audio from up to 28
devices.
Selectable configuration roles when connecting to an intercom matrix and an Xpeak system.
Programmable front-panel keys.
With a matrix: Up to four configuration pages
for the four programmable keys (sixteen
virtual keys).
In matrix-free Xpeak mode: Up to two
configuration pages for the four
programmable keys (eight virtual keys).
Menu key configuration options:
– Working mode: Matrix-free Xpeak or connected to a matrix.
– Audio codec selection.
– Trigger level selection (noise gate).
– Connection status information.
– Send test tone.
Audio Codecs:
– G711, and G722, depending on the operating mode and connected matrix. It also includes the Kroma legacy VoIP K711.
Key Commands:
– Talk
– Listen
– Talk&Listen
– Remote One Way
– Remote Both Ways
– Remote Volume
– Dial Call
Internal antenna.
Water splash resistant.

Dimensions and weight approximately

-Width: 92 mm.
– Height: 130 mm.
– Depth: 70 mm.
– Weight: 365 g.

Power and Charging

-High-capacity internal battery: up to 10 hours of operation.
– Charging base for 5 devices.
– Charging time: approximately 3 hours.
